Filtermist Product Code:26-253-01-175

Manufacturer's Part No:852902TI07/1-0.5V4A Food

Material
Media
Diameter
Length
Filter Surface
Connection
Material
Stainless Steel
Media
Polyester / PTFE Membrane
Diameter
120mm
Length
300 mm
Filter Surface
0,5 m²
Connection
Threaded connection RD72

Additional information:

  • PTFE-Membrane, Antistatic
  • FDA Approved

PTFE Membranes

  • High efficiency (99% to 0.3 micron)
  • Good product release on sticky particles
  • Moisture resistant
  • Anti-static options for static prone and explosive dusts

Stainless steel wire mesh

A special form of surface treatment has been used to obtain a very smooth, finely separating filter media. The wire mesh structure permits wet cleaning without removing the cartridge. This media is ideal for use in cleanable dust filters installed in dry dust removal applications in the food processing and pharmaceuticals industries.

Characteristics

  • Smooth surface
  • Electrically conductive
  • Good separation efficiency
  • Excellent cleaning power
  • Good cleanability

Glass fiber

This filter media consists of a microglass fibre fleece with spun-bonded polyester fleece laminated on one side and cellulose paper laminated on the other. It is characterised by good separation in the HEPA range. Cartridges made of this media are normally used in non-cleanable secondary filters.

Characteristics

  • Very high separation efficiency
  • High mechanical strength
  • Compliance with the requirements of DIN EN 60335-2-69/Dust class "H" and EN 1822-3 class "H14" at v ≤ 1m/min
  • Filter media conforms to regulations (EC) No. 1935/2004 and (EU) No. 10/2011 as well as FDA 21 CFR CH. I §177.1550 requirement

Polypropylene

  • Higher efficiency mid-range product - 99% to 2 micron

HEPA Rated

  • HEPA rated medias are available across Dustcheck’s complete product range
  • Manufactured to H13 and H14 HEPA ratings
  • Suitable for toxic processes
  • Suitable where low emissions is an installation criteria
  • Suitable for secondary filtration units where cleaned air is to be returned to the atmosphere

    -
